Angular 5.* Lighthouse Primer

Apr 14, 2018 https://github.com/alejandroq/angular-primer

This article was originally part of my “edu” series originally publicized via a GitHub repository and live presented to a group of peers. Therefore much of it is organized in a manner meant to direct said presentation and is not optimized as an article.

Get Started
Steps
Migrate from Angular5 to Angular6
Routes
Extra Credit
- Prettier and VSCode

Get Started

Install the following dependencies:

Angular CLI
NPM or Yarn

We will be using Angular 5 and Angular CLI 1.6.

Steps

Create an NG application

$ ng new ngapp --service-worker --routing

Let’s benchmark with Lighthouse and ng build --prod --aot:

PWA Stats

Create an App Shell

$ npm install @angular/platform-server
$ ng generate universal ngu-app-shell
$ ng generate app-shell loading-shell \
    --universal-app=ngu-app-shell \
    --route=app-shell-path

Let’s benchmark with Lighthouse and ng build --prod --aot:

Stats

What is enabled with a Shell vs no Shell besides ~600ms First-Paint speed saved for a 3G connection? Rehydration!

<!DOCTYPE html><html lang="en"><head><meta charset="utf-8"><title>Ngapp</title><base href="/"><meta name="viewport" content="width=device-width,initial-scale=1"><link rel="icon" type="image/x-icon" href="favicon.ico"><link href="styles.9c0ad738f18adc3d19ed.bundle.css" rel="stylesheet"><style ng-transition="serverApp"></style></head><body><app-root _nghost-c0="" ng-version="5.2.9"></app-root><script type="text/javascript" src="inline.69fe2ea4c1357caad977.bundle.js"></script><script type="text/javascript" src="polyfills.46af3f84a403e219371b.bundle.js"></script><script type="text/javascript" src="main.3f0a915399c6ba87014e.bundle.js"></script></body></html>

<!DOCTYPE html><html lang="en"><head><meta charset="utf-8"><title>Ngapp</title><base href="/"><meta name="viewport" content="width=device-width,initial-scale=1"><link rel="icon" type="image/x-icon" href="favicon.ico"><link href="styles.9c0ad738f18adc3d19ed.bundle.css" rel="stylesheet"><style ng-transition="serverApp"></style></head><body><app-root _nghost-c0="" ng-version="5.2.9">
<div _ngcontent-c0="" style="text-align:center">
  <h1 _ngcontent-c0="">
    Welcome to app!
  </h1>
</div>
<h2 _ngcontent-c0="">Here are some links to help you start: </h2>
<ul _ngcontent-c0="">
  <li _ngcontent-c0="">
    <h2 _ngcontent-c0=""><a _ngcontent-c0="" href="https://angular.io/tutorial" rel="noopener" target="_blank">Tour of Heroes</a></h2>
  </li>
  <li _ngcontent-c0="">
    <h2 _ngcontent-c0=""><a _ngcontent-c0="" href="https://github.com/angular/angular-cli/wiki" rel="noopener" target="_blank">CLI Documentation</a></h2>
  </li>
  <li _ngcontent-c0="">
    <h2 _ngcontent-c0=""><a _ngcontent-c0="" href="https://blog.angular.io/" rel="noopener" target="_blank">Angular blog</a></h2>
  </li>
</ul>

<router-outlet _ngcontent-c0=""></router-outlet><app-shell _nghost-c1=""><p _ngcontent-c1="">
  app-shell works!
</p>
</app-shell>
</app-root><script type="text/javascript" src="inline.69fe2ea4c1357caad977.bundle.js"></script><script type="text/javascript" src="polyfills.46af3f84a403e219371b.bundle.js"></script><script type="text/javascript" src="main.3f0a915399c6ba87014e.bundle.js"></script></body></html>

In our previous benchmark, there is render-blocking stylesheet. Let’s remove it by removing references to "styles.css" in the .angular-cli.json. The end result should be:

{
  "$schema": "./node_modules/@angular/cli/lib/config/schema.json",
  "project": {
    "name": "ngapp"
  },
  "apps": [
    {
      "root": "src",
      "outDir": "dist",
      "assets": ["assets", "favicon.ico"],
      "index": "index.html",
      "main": "main.ts",
      "polyfills": "polyfills.ts",
      "test": "test.ts",
      "tsconfig": "tsconfig.app.json",
      "testTsconfig": "tsconfig.spec.json",
      "prefix": "app",
      "styles": [],
      "scripts": [],
      "environmentSource": "environments/environment.ts",
      "environments": {
        "dev": "environments/environment.ts",
        "prod": "environments/environment.prod.ts"
      },
      "serviceWorker": true,
      "appShell": {
        "app": "ngu-app-shell",
        "route": "app-shell-path"
      }
    },
    {
      "root": "src",
      "outDir": "dist-server",
      "assets": ["assets", "favicon.ico"],
      "index": "index.html",
      "main": "main.server.ts",
      "test": "test.ts",
      "tsconfig": "tsconfig.server.json",
      "testTsconfig": "tsconfig.spec.json",
      "prefix": "app",
      "styles": [],
      "scripts": [],
      "environmentSource": "environments/environment.ts",
      "environments": {
        "dev": "environments/environment.ts",
        "prod": "environments/environment.prod.ts"
      },
      "serviceWorker": true,
      "platform": "server",
      "name": "ngu-app-shell"
    }
  ],
  "e2e": {
    "protractor": {
      "config": "./protractor.conf.js"
    }
  },
  "lint": [
    {
      "project": "src/tsconfig.app.json",
      "exclude": "**/node_modules/**"
    },
    {
      "project": "src/tsconfig.spec.json",
      "exclude": "**/node_modules/**"
    },
    {
      "project": "e2e/tsconfig.e2e.json",
      "exclude": "**/node_modules/**"
    }
  ],
  "test": {
    "karma": {
      "config": "./karma.conf.js"
    }
  },
  "defaults": {
    "styleExt": "css",
    "component": {}
  }
}

Let’s benchmark with Lighthouse and ng build --prod --aot:

Stats

Our Lighthouse First-Paint speed for a 3G connection in this case was 800ms.

Let’s update a few of the meta PWA tasks. First edit the index.html as so to accomodate specific meta data:

<!doctype html>
<html lang="en">

<head>
  <meta charset="utf-8">
  <title>Ngapp</title>
  <base href="/">
  <link rel="manifest" href="assets/manifest.json">
  <meta name="description" content="An example Angular5 application with Service Worker" />
  <meta name="theme-color" content="#f2f2f2">

  <meta name="mobile-web-app-capable" content="yes">
  <meta name="viewport" content="width=device-width, initial-scale=1">
  <link rel="icon" type="image/x-icon" href="favicon.ico">
</head>

<body>
  <app-root></app-root>
  <noscript>
    Javascript must be enabled to use this app.
  </noscript>
</body>

</html>

Note the new <noscript> tags and <meta> tags.

Create a assets/manifest.json:

{
  "short_name": "Ngapp",
  "name": "Angular 5.0 PWA",
  "start_url": "/",

  "theme_color": "#f2f2f2",
  "background_color": "#ffffff",

  "display": "standalone",
  "orientation": "portrait",

  "icons": [
    {
      "src":
        "../../../images/angular-5-lighthouse-primer/icons/android-chrome-512x512.png",
      "sizes": "512x512",
      "type": "image/png"
    }
  ]
}

The browser requires the manifest.json for prompting web app download to device.

Let’s benchmark with Lighthouse and ng build --prod --aot:

Stats

Our PWA score is now 91. When we deliver via HTTPS, it will be 100.

Migrate from Angular5 to Angular6

If you already maintain an application and would rather not replace your entire package.json; checkout this upgrade guide

Let’s update out experiment from Angular5 to Angular6-rc4. Replace your package.json as so and then run rm -r node_modules && npm install:

{
  "name": "ngapp",
  "version": "0.0.0",
  "license": "MIT",
  "scripts": {
    "ng": "ng",
    "start": "ng serve",
    "build": "ng build --prod",
    "test": "ng test",
    "lint": "ng lint",
    "e2e": "ng e2e"
  },
  "private": true,
  "dependencies": {
    "@angular-devkit/core": "0.5.6",
    "@angular/animations": "^6.0.0-rc.4",
    "@angular/common": "^6.0.0-rc.4",
    "@angular/compiler": "^6.0.0-rc.4",
    "@angular/core": "^6.0.0-rc.4",
    "@angular/forms": "^6.0.0-rc.4",
    "@angular/http": "^6.0.0-rc.4",
    "@angular/platform-browser": "^6.0.0-rc.4",
    "@angular/platform-browser-dynamic": "^6.0.0-rc.4",
    "@angular/platform-server": "^6.0.0-rc.4",
    "@angular/router": "^6.0.0-rc.4",
    "@angular/service-worker": "^6.0.0-rc.4",
    "core-js": "^2.4.1",
    "rxjs": "^6.0.0-beta.1",
    "rxjs-compat": "^6.0.0-uncanny-rc.7",
    "zone.js": "^0.8.26"
  },
  "devDependencies": {
    "@angular-devkit/core": "0.3.2",
    "@angular-devkit/schematics": "^0.5.6",
    "@angular/cli": "1.7.4",
    "@angular/compiler-cli": "^6.0.0-rc.4",
    "@angular/language-service": "^6.0.0-rc.4",
    "@types/jasmine": "~2.8.6",
    "@types/jasminewd2": "~2.0.2",
    "@types/node": "~9.6.5",
    "codelyzer": "^4.0.1",
    "jasmine-core": "~3.1.0",
    "jasmine-spec-reporter": "~4.2.1",
    "karma": "~2.0.0",
    "karma-chrome-launcher": "~2.2.0",
    "karma-cli": "~1.0.1",
    "karma-coverage-istanbul-reporter": "^1.2.1",
    "karma-jasmine": "~1.1.0",
    "karma-jasmine-html-reporter": "^1.0.0",
    "protractor": "~5.3.1",
    "ts-node": "~5.0.1",
    "tslint": "~5.9.1",
    "typescript": "2.7.2"
  }
}

AngularCLI 1.7 comes with a bundle analyzer. Update your .angular-cli.json accordingly to enable:

{
  "$schema": "./node_modules/@angular/cli/lib/config/schema.json",
  "project": {
    "name": "ngapp"
  },
  "apps": [
    {
      "root": "src",
      "outDir": "dist",
      "assets": ["assets", "favicon.ico"],
      "index": "index.html",
      "main": "main.ts",
      "polyfills": "polyfills.ts",
      "test": "test.ts",
      "tsconfig": "tsconfig.app.json",
      "testTsconfig": "tsconfig.spec.json",
      "prefix": "app",
      "styles": [],
      "scripts": [],
      "environmentSource": "environments/environment.ts",
      "environments": {
        "dev": "environments/environment.ts",
        "prod": "environments/environment.prod.ts"
      },
      "serviceWorker": true,
      "appShell": {
        "app": "ngu-app-shell",
        "route": "app-shell-path"
      },
      "budgets": [
        {
          "type": "bundle",
          "name": "main",
          "baseline": "300kb",
          "warning": "30kb"
        },
        { "type": "bundle", "name": "races", "maximumWarning": "360kb" },
        { "type": "allScript", "baseline": "1.4mb", "maximumError": "100kb" },
        { "type": "initial", "baseline": "1.6mb", "error": "100kb" },
        { "type": "any", "maximumError": "500kb" }
      ]
    },
    {
      "root": "src",
      "outDir": "dist-server",
      "assets": ["assets", "favicon.ico"],
      "index": "index.html",
      "main": "main.server.ts",
      "test": "test.ts",
      "tsconfig": "tsconfig.server.json",
      "testTsconfig": "tsconfig.spec.json",
      "prefix": "app",
      "styles": [],
      "scripts": [],
      "environmentSource": "environments/environment.ts",
      "environments": {
        "dev": "environments/environment.ts",
        "prod": "environments/environment.prod.ts"
      },
      "serviceWorker": true,
      "platform": "server",
      "name": "ngu-app-shell"
    }
  ],
  "e2e": {
    "protractor": {
      "config": "./protractor.conf.js"
    }
  },
  "lint": [
    {
      "project": "src/tsconfig.app.json",
      "exclude": "**/node_modules/**"
    },
    {
      "project": "src/tsconfig.spec.json",
      "exclude": "**/node_modules/**"
    },
    {
      "project": "e2e/tsconfig.e2e.json",
      "exclude": "**/node_modules/**"
    }
  ],
  "test": {
    "karma": {
      "config": "./karma.conf.js"
    }
  },
  "defaults": {
    "styleExt": "css",
    "component": {}
  }
}

Let’s benchmark with Lighthouse and ng build --prod --aot:

Stats

Its “First-Paint” time has greatly improved! A feat accomplished by a simple upgrade. How significant is every 100ms?

How does our bundle analysis look?

Bundle Analysis

Routes

Lets create a lazy loaded route.

$ ng g m routetwo --skip-import && ng g c routetwo --skip-import

Apply this to your src/app-routing.module.ts:

const routes: Routes = [
  {
    path: "",
    pathMatch: "full",
    component: AppComponent
  },
  {
    path: "routetwo",
    pathMatch: "full",
    loadChildren: "./routes/routetwo/routetwo-routing.module#RoutetwoModule"
  },
  {
    path: "**",
    pathMatch: "full",
    redirectTo: ""
  }
];

The NG CLI will intelligently chunk the RoutetwoModule. When a user visits said route, the module will lazy load without the user savvy.

The src/routes/routetwo-routing.module.ts should look as so:

import { NgModule } from "@angular/core";
import { Routes, RouterModule } from "@angular/router";
import { RoutetwoComponent } from "./routetwo.component";

const routes: Routes = [
  {
    path: "",
    pathMatch: "full",
    component: RoutetwoComponent
  },
  {
    path: "**",
    pathMatch: "full",
    redirectTo: ""
  }
];

@NgModule({
  imports: [RouterModule.forChild(routes)],
  exports: [RouterModule],
  declarations: [RoutetwoComponent]
})
export class RoutetwoRoutingModule {}

This module will handle component declaration and sub-routes for the RotuetwoModule. Further layers can also be lazy loaded as handled before.

Extra Credit

Prettier and VSCode

For code formatting lets take advantage of VSCode’s plugin for PrettierJS. This specific plugins identifier is as so: esbenp.prettier-vscode.
Create a .prettierrc file with the following contents:

{
  "singleQuote": true,
  "trailingComma": "es5",
  "bracketSpacing": true
}

Create a settings.json with the following contents:

{
  "editor.formatOnSave": true,
  "[javascript]": {
    "editor.formatOnSave": true
  }
}

What does this do? View the following before and after. The before becomes the after upon saving the document:

import { NgModule } from '@angular/core';
import { Routes, RouterModule } from '@angular/router';
import { RoutetwoComponent } from './routetwo.component';

const routes: Routes = [
  { path: '', pathMatch:
  'full', component: RoutetwoComponent },
  {
    path: '**', pathMatch: 'full', redirectTo: '' },
];

@NgModule({
  imports: [RouterModule.forChild(routes)],
  exports: [
    RouterModule

  ],
  declarations: [RoutetwoComponent],
})
export class RoutetwoRoutingModule {



}

import { NgModule } from "@angular/core";
import { Routes, RouterModule } from "@angular/router";
import { RoutetwoComponent } from "./routetwo.component";

const routes: Routes = [
  {
    path: "",
    pathMatch: "full",
    component: RoutetwoComponent
  },
  {
    path: "**",
    pathMatch: "full",
    redirectTo: ""
  }
];

@NgModule({
  imports: [RouterModule.forChild(routes)],
  exports: [RouterModule],
  declarations: [RoutetwoComponent]
})
export class RoutetwoRoutingModule {}
